ES Series

A truly scalable system, it is compact and modular with all the electronics and amplification housed in separate, portable units – the EPAK 2500 and 2500R. Placing the active electronics package outboard results in a lighter, easier to handle system with much more flexibility. Its compact size reduces transport costs and either ground stacked or own, it is quick and easy to setup, cutting labour costs dramatically. The EPAK 2500/R control unit incorporates four amplifiers. Electronic crossover filters, time alignment, equalization, system protection, and level controls are all done onboard, utilizing industry leading 20MHz digital conversion where required.

Watch the video


ESOverview

Description

The ES1.0 Mid/High speaker and the EPAK2500/R make up the core of the amazing sounding, incredibly dynamic ES system. Each ES1.0 requires an EPAK2500/R to power it and the three way cabinet includes a 12” horn loaded mid bass driver, 6” horn loaded mid speaker, and 1.75" Titanium compression driver. You can rotate the ES 1.0 horn assembly in order to run the system in a vertical or horizontal configuration, and couple two ES1.0 cabinets together horizontally to create a very powerful, long throw solution.

As well as driving the three way ES1.0 cabinet, a fourth amplifier channel in the EPAK2500/R control unit is dedicated to powering a choice of ES series subwoofers. The ES1.5 is a lightweight single 15” enclosure, the ES1.8 a horn reflex, single 18” subwoofer and the ES2.5 /2.6 a double 15”, twin asymmetrical design, available in either four Ohm (ES2.5) or eight Ohm (ES2.6) versions.

Simple to set up and use The ES System has been designed for plug and play operation. It would take a dozen or more outboard components, sophisticated measuring equipment and a degree in acoustic engineering to achieve the optimization we’ve built into the EPAK 2500/R. A multi position switch allows you to select from various subwoofer combinations, you decide which plug and play bass modules you want to use, select and go.

The meticulously designed control electronics inside the EPAK2500/R constantly monitor and preserve the relationship between each amplifier and component, delivering exactly the right amount and type of power throughout the system. When you’re able to perfectly match an amplifier with a transducer you start to unlock incredible performance that is impossible to achieve with passive systems. Total system reliability increases dramatically as does sound quality. With this kind of precision and efficiency built in, you’ll be amazed at the quality, depth, level and resolution produced by an ES system.

Features

Specifically designed as an extreme high output, compact mid-high enclosure as part of ES systems

  • For live performance and music playback
  • Small to large live concerts
  • Small to medium nightclubs
  • Houses of worship
  • Portable PA
PDF

ES Speakers User Guide

ES1.0, ES1.5, ES1.8, ES2.5, ES2.6 User Guide - English, rev. 7



PDF

ES Cabinets Configurations User Guide

- ES Series - Basic single and double configurations user guide



PDF

ES Flyware - Suspension and Rigging

ES Flyware - Suspension and Rigging - English



PDF

Disarray - The correct theory of arraying KV2 boxes

Disarray - The correct theory of arraying KV2 boxes



PDF

ES1.5 Data Sheet

ES1.5 Data Sheet



PDF

ES1.8 Data Sheet

ES1.8 Data Sheet



PDF

ES2.5 Data Sheet

ES2.5 Data Sheet



PDF

ES2.6 Data Sheet

ES2.6 Data Sheet



PDF

EPAK2500 User Guide

- User Guide for EPAK2500 Amplifier - English



PDF

EPAK2500 Data Sheet

EPAK2500 Data Sheet



PDF

EPAK2500R User Guide

- User Guide for EPAK2500R Amplifier - English



PDF

Security panel User guide

- User Guide for Security panel installation - english



PDF

EPAK2500R Data Sheet

EPAK2500R Data Sheet



DWG

ESD15 / ES1.0 / ES1.5 / EX15 Vertical Bracket 2D DWG

ESD15 / ES1.0 / ES1.5 / EX15 Vertical Bracket 2D DWG



DWG

ESD15 / ES1.0 / ES1.5 Horizontal Bracket 2D DWG

ESD15 / ES1.0 / ES1.5 Horizontal Bracket 2D DWG



DWG

ES1.0 2D DWG

ES1.0 2D DWG



PDF

ES1.0 - 2D

ES1.0 2D Drawings



DWG

ES1.0 - 3D

1:1 scale - clamping points - weight - dwg file



DWG

ES1.5 - 3D

1:1 scale - clamping points - weight - dwg file



PDF

ES1.5 - 2D

ES1.5 2D Drawings



DWG

ES1.5 2D DWG

ES1.5 2D DWG



DWG

ES1.8 - 3D

1:1 scale - clamping points - weight - dwg file



PDF

ES1.8 - 2D

ES1.8 2D Drawings



DWG

ES1.8 2D DWG

ES1.8 2D DWG



DWG

ES2.5 - 3D

1:1 scale - clamping points - weight - dwg file



PDF

ES2.5 - 2D

ES2.5 2D Drawings



DWG

ES2.5 2D DWG

ES2.5 2D DWG



DWG

ES2.6 - 3D

1:1 scale - clamping points - weight - dwg file



PDF

ES2.6 - 2D

ES2.6 2D Drawings



DWG

ES2.6 2D DWG

ES2.6 2D DWG



DWG

EPAK2500 CLOSED - 3D

with lid - 1:1 scale - clamping points - weight - dwg file



DWG

EPAK2500 OPEN - 3D

without lid - 1:1 scale - clamping points - weight - dwg file



PDF

EPAK2500 - 2D

EPAK2500 2D Drawings



DWG

EPAK2500 2D DWG

EPAK2500 2D DWG



DWG

EPAK2500R - 2D

EPAK2500R 2D Drawings



PDF

EPAK2500R - 2D

EPAK2500R 2D Drawings



DWG

EPAK2500R - 3D

1:1 scale - clamping points - weight - dwg file



DWG

EPAK2500R 2D DWG

EPAK2500R 2D DWG



GLL

ES1.0 - EASE data

EASE data - .GLL - description



PDF

Technology

Super Live Audio Technology (SLA)



GLL

ES1.0 EASE Focus

ES1.0 EASE Focus







ES1.0, ES1.5, ES1.8, ES2.5, ES2.6 Bracket additional arms

Gallery





Product code

KVV 987 192



Description

- 2 pcs ARMS OF FB-0002
- 8 pcs M10 screws
- 8 pcs Quick-lock-pins 6mm included





EPAK2500, EPAK2500R, ES1.0, ESR2800, ESR3000MkII, SL3000, SL412 Amphenol AP6 connector

Gallery





Product code

KVV 987 050



Description

- female - cable mount





EPAK2500, EPAK2500R, ES1.0, ESR2800, ESR3000MkII, SL3000, SL412 Amphenol AP6 connector

Gallery





Product code

KVV 987 051



Description

- male - cable mount





Cable Kit

Gallery





Product code

KVV 987 047



Description

- consist of four high-quality Amphenol AP cable assemblies designed for use with ES Series - 2 pcs LF15 - 1pc LF40 - 1pc MH60





Cable MH120

Gallery





Product code

KVV 987 126



Description

- 6 wire speaker cable - AP6 connectors - 12m (40ft) length - for Mid/Hi Module hook-up





Cable MH15

Gallery





Product code

KVV 987 147



Description

- 6 wire speaker cable - AP6 connectors - 1,5m (5ft) length - for Mid/Hi Module connection - for VHD1.0 Mid/Hi Module daisy-chaining





Cable MH180

Gallery





Product code

KVV 987 127



Description

- 6 wire speaker cable - AP6 connectors - 18m (60ft) length - for Mid/Hi Module hook-up





Mid/Hi speaker cable HM60

Gallery





Product code

KVV 987 125



Description

- 6 wire speaker cable - AP6 connectors - 6m (20ft) - for Mid/Hi Module hook-up




ES1.0, ES1.5, EX1.8, EX2.2 Cart wheels

Gallery





Product code

KVV 987 031



Description

- with bolts nuts kit - 4 pcs in pack, rotating, blue
- 16x M8x 25mm Screw Countersunk Hexagon Socket Head
- 16x Nut Hexagon with blue plastic insert M8





ES Downfill bracket

Gallery





Product code

KVV 987 311



Description

- 4 pcs Quick-lock-pins 6mm included
- 4 pcs M10 hex screws included
- 1pc allen key
- 6mm included





ES System flybar and bracket

Gallery





Product code

KVV 987 191



Description

- 8 pcs M10 screws - 8 pcs Quick-lock-pins 6mm included - 4 pcs Quick-lock-pins 1/2inch included





ES1.0 Heavy duty cover

Gallery





Product code

KVV 987 119



Description

- Durable material





ES1.0 Full grille

Gallery





Product code

KVV 987 131



Description

Optional full grille for ES1.0





ES1.0, ES1.5 Cart

Gallery





Product code

KVV 987 030



Description

- for 2pcs ES1.0 or ES 1.5 - wheels not included
- 16x M8x 25mm Screw Countersunk Hexagon Socket Head
- 16x Nut Hexagon with blue plastic insert M8





ES1.0, ES1.5, ESD15 Horizontal bracket

Gallery





Product code

KVV 987 035



Description

- for ES1.0, ES1.5, ESD15 (or eventually for EX15 when positioned vertically) - including top hat cover adaptor plate and two connection bolts - black





ES1.0, ES1.5, ESD15, EX15 Vertical bracket

3D visualisation

Gallery





Product code

KVV 987 032



Description

- for ES1.0, ES1.5, ESD15, EX15 - including two connection bolts - black



Downloads

DWG

ESD15 / ES1.0 / ES1.5 / EX15 Vertical Bracket 2D DWG

ESD15 / ES1.0 / ES1.5 / EX15 Vertical Bracket 2D DWG






Set of M10 x 50 closed end bolts for 6mm quick lock pin for ES1.0, ES1.5, ESR212, ESR215MkII, SL2.15, SL412

Gallery





Product code

KVV 987 383



Description

These negate the requirement to remove and replace supplied enclosure bolts depending if attachments are fixed.





Speaker pole - universal

Gallery





Product code

KVV 987 130



Description

Heavy duty telescopic speakerpole
- 0,735 to 1,23 m - diameter 35 mm
- weight 2,2 kg - max. load 50 kg
- bottom terminal M20
- matte black





EPAK2500, EPAK2500R, ES1.5, ES1.8, ES2.5, ES2.6, SL2.15 Amphenol AP4 connector

Gallery





Product code

KVV 987 048



Description

- female - cable mount





EPAK2500, EPAK2500R, ES1.5, ES1.8, ES2.5, ES2.6, SL2.15 Amphenol AP4 connector

Gallery





Product code

KVV 987 049



Description

- male - cable mount





Cable LF100 for bass speaker

Gallery





Product code

KVV 987 123



Description

- 4 wire speaker cable - AP4 connectors - 10m (33ft) - for ES Bass Module hook-up





Cable LF15

Gallery





Product code

KVV 987 121



Description

- 4 wire speaker cable - AP4 connectors - 1,5m (5ft) - for ES Bass Module daisy-chaining





Cable LF200 for bass speaker

Gallery





Product code

KVV 987 124



Description

- 4 wire speaker cable - AP4 connectors - 20m (66ft) - for ES Bass Module hook-up





Cable LF40

Gallery





Product code

KVV 987 122



Description

- 4 wire speaker cable - AP4 connectors - 4m (13ft) - for ES Bass Module hook-up





ES1.5 Cover heavy duty cover

Gallery





Product code

KVV 987 120



Description

- Durable material





Cart wheels for ES1.8, ES2.5, ES2.6, EX2.5 MkII, KT2.15

Gallery





Product code

KVV 987 128



Description

- with bolts nut kit - 4 pcs in pack, rotating, blue
- 16x M8x 35mm Screw Countersunk Hexagon Socket Head
- 16x Nut Hexagon with blue plastic insert M8





ES1.8 Cover with cart

Gallery





Product code

KVV 987 116



Description

- Durable material





ES1.8 Cover without cart

Gallery





Product code

KVV 987 115



Description

- Durable material





Front mount magnetic cart for ES1.8, ES2.5, ES2.6, EX2.5MkII

Gallery





Product code

KVV 987 114



Description

- wheels not included
- 16x M8x 35mm Screw Countersunk Hexagon Socket Head
- 16x Nut Hexagon with blue plastic insert M8-





ES2.5 Cover with cart

Gallery





Product code

KVV 987 118



Description

- Durable material





ES2.5 Cover without cart

Gallery





Product code

KVV 987 117



Description

- Durable material





ES2.6 Cover with cart

Gallery





Product code

KVV 987 154



Description

- Durable material





ES2.6 Cover without cart

Gallery





Product code

KVV 987 153



Description

- Durable material





Super Digital 20MHz, delay board for EPAK2500

Gallery





Product code

KVV 987 253



Description

- electronic board - exchange requires professional installation - additional heatsink, nuts included





EPAK2500 Wallmount bracket

Gallery





Product code

KVV 987 332



Description

- wall mounting kit for installing an EPAK2500 or KPAK2500 - for 1pc EPAK2500 or KPAK2500





Super Digital 20MHz, delay board for EPAK2500R

Gallery





Product code

KVV 987 294



Description

- electronic board - exchange requires professional installation





EPAK2500R, ESP4000, VHD2000 Rack panel cover

Gallery





Product code

KVV987189



Description

- prevents unwanted amplifier setup - 4U






Q: When I hang either a single or a double ES1.0 in the HORIZONTAL mode, does it matter which way the enclosure is presented? For example should the horn assembly be on the 'outside', or should the port be on the 'outside', does it matter?

A: YES, this is very important, when hanging either a single or a double ES1.0 enclosure, in a Left/Right configuation, the left hang should have the horn on the 'outside', port on the 'inside, similarly, the right hang should mirror this effect.
The reasons for this are that the enclosure and horn are designed to disperse the sound in a downward effect,(approx 10-15deg depending on frequency), and similarly to reduce reflections from the outside walls and perimiters.



Q: I want to use more than one single ES1.0 per side of the stage; can I place them together like an Array?

All KV2 Audio loudspeaker units are designed with low loss, low compression horn assemblies and are low’q’.
Their wide dispersion aspects mean that physical side by side ‘arraying’ is not the correct method or way to utilize the loudspeakers in application, primarily due to the interaction effects which cause poor phase response, frequency response and in-accurate dispersion.
It is entirely feasible to utilize a combination of two ES1.0 enclosures, providing that they are located and placed as highlighted in the picture below.

Please refer to the ‘Technology’ tab or download Disarray-Theory



Q: Can I use my existing EX2.5 or EX1.8 active subwoofer to add to an ES system consisting of either ES2.5/2.6 or ES1.8 subwoofers?

Yes, it is possible to use any of the EX Subwoofers as an extension, or addition to other KV2 product ranges, however it is important to recognize and understand that the phase of all the EX subwoofers is ‘Opposite’ to the ES subwoofers, so to use in a correct manner and to achieve the desired effect of ‘addition’, a reverse phase XLR connector will be required.

* Please note: If you are using the EX2.5 MkII, then you will need to add a single passive ES2.6 to maintain full output and balance of the system.



Q: I would like to have a separate signal for subs on EPAK2500R and then send it to forward to another EPAK2500R? How do you recommend wiring and Inserts buttons position?

The ES is designed as a complete system for optimum performance with regards to integration and therefore we do not recommend separating subwoofer operation from the main input feed. However if there is an important requirement to do this please refer to the chapter Using the system of EPAK2500R user manual.



Q: How to set up cardioid Sub patterns with ES and VHD systems?

The quickest route to understanding and applying cardioid sub patterns is to refer to the SDD3 user manual page 8 and 9. If you require further instructions please contact your local dealer.




ES Double - A



Description

Up to 2000 people. Number of bass boxes depends on music style. One side of stereo single system.

Note: Selection of ES amplifier model style is optional (either EPAK2500 or EPAK2500R).



Products

CountProductType
2ES1.0MID-HI
1ES2.5SUB
2ES1.8SUB
2EPAK2500R or EPAK2500AMP


Accessories

CountAccessoryTitle
2Cable MH60Mid/Hi speaker cable HM60
2Cable LF40Cable LF40
1Cable LF15Cable LF15


Images

Front viewWiring




ES Double - B



Description

Up to 2000 people. Number of bass boxes depends on music style. One side of stereo single system.

Note: Selection of ES amplifier model style is optional (either EPAK2500 or EPAK2500R).



Products

CountProductType
2ES1.0MID-HI
4ES1.8SUB
2EPAK2500R or EPAK2500AMP


Accessories

CountAccessoryTitle
1ES System flybar and bracketES System flybar and bracket
2Cable MH120Cable MH120
0Cable LF15Cable LF15
2Cable LF40Cable LF40
2Cable LF15Cable LF15


Images

Front viewWiring




ES Double - C



Description

Up to 2000 people. Number of bass boxes depends on music style. One side of stereo single system.

Note: Selection of ES amplifier model style is optional (either EPAK2500 or EPAK2500R).



Products

CountProductType
2ES2.5SUB
2ES1.0MID-HI
2EPAK2500R or EPAK2500AMP


Accessories

CountAccessoryTitle
1ES System flybar and bracketES System flybar and bracket
2Cable MH120Cable MH120
2Cable LF40Cable LF40


Images

Front viewWiring




ES Double - D



Description

Up to 2000 people. Number of bass boxes depends on music style. One side of stereo single system.

Note: Selection of ES amplifier model style is optional (either EPAK2500 or EPAK2500R).



Products

CountProductType
2ES1.0MID-HI
4ES2.6SUB
2EPAK2500R or EPAK2500AMP


Accessories

CountAccessoryTitle
1ES System flybar and bracketES System flybar and bracket
2Cable MH120Cable MH120
2Cable LF40Cable LF40
2Cable LF15Cable LF15


Images

Front viewWiring




ES Single - A1



Description

Up to 1000 people. Number of bass boxes and SUB LEVEL setup depend on music style. One side of stereo single system.

Note: Selection of ES amplifier model style is optional (either EPAK2500 or EPAK2500R).



Products

CountProductType
1ES1.0MID-HI
1ES1.5SUB
1EPAK2500R or EPAK2500AMP


Accessories

CountAccessoryTitle
1Cable LF40Cable LF40
1Cable MH60Mid/Hi speaker cable HM60


Images

Front viewWiring




ES Single - A2



Description

Up to 1000 people. Number of bass boxes depends on music style. One side of stereo single system.

Note: Selection of ES amplifier model style is optional (either EPAK2500 or EPAK2500R).



Products

CountProductType
1ES1.0MID-HI
2ES1.5SUB
1EPAK2500R or EPAK2500AMP


Accessories

CountAccessoryTitle
1Cable MH60Mid/Hi speaker cable HM60
1Cable LF40Cable LF40
1Cable LF15Cable LF15


Images

Front viewWiring




ES Single - A3



Description

Up to 1000 people. Number of bass boxes depends on music style. One side of stereo single system.

Note: Selection of ES amplifier model style is optional (either EPAK2500 or EPAK2500R).



Products

CountProductType
1ES1.0MID-HI
3ES1.5SUB
1EPAK2500R or EPAK2500AMP


Accessories

CountAccessoryTitle
1Cable MH60Mid/Hi speaker cable HM60
1Cable LF40Cable LF40
2Cable LF15Cable LF15


Images

Front viewWiring




ES Single - B1



Description

Up to 1000 people. Number of bass boxes depends on music style. One side of stereo single system.

Note: Selection of ES amplifier model style is optional (either EPAK2500 or EPAK2500R).



Products

CountProductType
1ES1.0MID-HI
2ES1.5SUB
1ES1.8SUB
1EPAK2500R or EPAK2500AMP


Accessories

CountAccessoryTitle
1Cable MH60Mid/Hi speaker cable HM60
1Cable LF40Cable LF40
2Cable LF15Cable LF15


Images

Front viewWiring




ES Single - B2



Description

Up to 1000 people. Number of bass boxes depends on music style. One side of stereo single system.

Note: Selection of ES amplifier model style is optional (either EPAK2500 or EPAK2500R).



Products

CountProductType
1ES1.0MID-HI
1ES2.6SUB
1ES1.8SUB
1EPAK2500R or EPAK2500AMP


Accessories

CountAccessoryTitle
1Cable MH60Mid/Hi speaker cable HM60
1Cable LF40Cable LF40
1Cable LF15Cable LF15


Images

Front viewAlternativeWiring




ES Single - C



Description

Up to 1000 people. Number of bass boxes depends on music style. One side of stereo single system.

Note: Selection of ES amplifier model style is optional (either EPAK2500 or EPAK2500R).



Products

CountProductType
1ES1.0MID-HI
1ES2.5SUB
1EPAK2500R or EPAK2500AMP


Accessories

CountAccessoryTitle
1Speaker pole - universalSpeaker pole - universal
1Cable MH60Mid/Hi speaker cable HM60
1Cable LF40Cable LF40


Images

Front viewWiring




ES Single - D



Description

Up to 1000 people. Number of bass boxes depends on music style. One side of stereo single system.

Note: Selection of ES amplifier model style is optional (either EPAK2500 or EPAK2500R).



Products

CountProductType
1ES1.0MID-HI
2ES2.6SUB
1EPAK2500R or EPAK2500AMP


Accessories

CountAccessoryTitle
1Cable MH60Mid/Hi speaker cable HM60
1Cable LF40Cable LF40
1Cable LF15Cable LF15


Images

Front viewAlternativeWiring




ES Single - E



Description

Up to 1000 people. Number of bass boxes depends on music style. One side of stereo single system.

Note: Selection of ES amplifier model style is optional (either EPAK2500 or EPAK2500R).



Products

CountProductType
1ES1.0MID-HI
2ES1.8SUB
1EPAK2500R or EPAK2500AMP


Accessories

CountAccessoryTitle
1Cable MH60Mid/Hi speaker cable HM60
1Cable LF40Cable LF40
1Cable LF15Cable LF15


Images

ES Single - EFront viewUsage






Distribution


The Future of Sound. Made Perfectly Clear.

© KV2 Audio 2021 – All rights reserved
