EX26 - 2-way Active speaker system

The EX26 is a unique Loudspeaker unit that provides superb vocal intelligibility and high quality musical reproduction. Its 100 x 100 degree horn provides for wide, even coverage making it ideal for audio visual presentations, churches, meeting rooms and various other applications where high quality speech reproduction is required. The EX26 makes an ideal under balcony fill speaker when used in a horizontal orientation.

Watch the product video

EX26 Technical Data Sheet

Applications

Purposely designed as a stand-alone unit for extremely high quality vocal reproduction and output

  • Church and houses of worship
  • Conference and presentations
  • Front of stage and balcony infill
  • Full range portable PA when used with subwoofers for larger Multi-Media applications and small live music applications

Product code

  • KVV 987 164 - EX26 230V
  • KVV 987 165 - EX26 115V


Features

  • Professional, Baltic birch construction with wear resistant polymer coating
  • 124dB sustained output, 127dB peak with very high dynamic range and low noise floor
  • 370W of total power with complete on-board speaker management system
  • 350W high efficiency, current enhancing, switching low frequency amplifier
  • Very high quality 20W, low IM distortion, Class AB, high frequency amplifier with transformer balanced output
  • Compact low profile cabinet design allows for use as a front fill or in under balcony applications with high pass filter to adjust equalization and phase response
  • Wide dispersion 100° H x 100° V horn
  • New patent pending 1.75" (44 mm) Nitride Titanium diaphragm compression driver with complex geometry phase plug for higher output, exceptionally low distortion, extended frequency response and neodymium magnet structure
  • Two 6" woofers feature neodymium magnetic motor structures that dramatically increase force, lower distortion and provide increased frequency response linearity
  • Proprietary top handle design for simplified handling and carrying, integrates one M10 suspension point, OmnimountTM bracket point and four M6 points
  • Additional side and bottom M10 points for flexible bracket, rigging and installation options
  • "Top-hat" pole mount fitted at the base of the cabinet
  • LED indicators for signal present and Power ON status


Applications

Purposely designed as a stand-alone unit for extremely high quality vocal reproduction and output

  • Church and houses of worship
  • Conference and presentations
  • Front of stage and balcony infill
  • Full range portable PA when used with subwoofers for larger Multi-Media applications and small live music applications

Product code

  • KVV 987 164 - EX26 230V
  • KVV 987 165 - EX26 115V


System Acoustic Performance

Max SPL Long-term124dB
Max SPL Peak130dB
-3dB Response80Hz to 20kHz
-10dB Response65Hz to 28kHz
Crossover Point2.5kHz

High Frequency Section

Acoustic DesignHorn Loaded
High Horn Coverage Horizontal / Vertical100° x 100°
Throat Exit Diameter / Diaphragm Size1" / 1.75"
Diaphragm MaterialNitride Titanium
Magnet TypeNeodymium

High Frequency Amplifier Specification

TypeClass AB Push-Pull
Rated Continuous Power20W
Distortion<0.05%
Operating Bandwidth2.5kHz to 28kHz

Low Frequency Section

Acoustic DesignFront Loaded, Bass Reflex
Woofer Size / Voice Coil Diameter / Design6" / 1.75"
Magnet TypeNeodymium
Diaphragm MaterialEpoxy Reinforced Cellulose

Low Frequency Amplifier Specification

TypeHigh efficiency, Current-Enhancing, Switched-Rail Amplifier
Rated Continuous Power350W
Distortion<0.05%
Operating Bandwidth68Hz to 2.5kHz

Signal Input

Input Sensitivity1V RMS
Input Impedance20 kΩ

Power Requirements

Power ConnectorNeutrik PowerCon®
Operating Voltage Range100 to 120V @ 60Hz | 230 to 250V @ 50Hz
Recommended Amperage3.15A 115V | 1.6A 230V

Cabinet

Cabinet MaterialBaltic birch
Handles1
Pole Mount35 mm
Color"Orange peeled" Matt Black or any RAL

Physical Dimensions

Height570 mm (22.44")
Width220 mm (8.66")
Depth274 mm (10.78")
Weight16 kg (35.2lbs)


Product code

  • KVV 987 164 - EX26 230V
  • KVV 987 165 - EX26 115V

PDF

EX Series User Guide

User Guide for EX6, EX10, EX12, EX15, EX26 and EX28 - English



PDF

EX26 Data Sheet

EX26 Data Sheet



DWG

EX26 - 3D

1:1 scale - clamping points - weight - dwg file



DWG

EX26 Vertical Bracket 3D DWG

EX26 Vertical Bracket 3D DWG



SKP

EX26 Horizontal Bracket SKP

EX26 Horizontal Bracket SketchUp



DWG

EX26 Horizontal Bracket 3D DWG

EX26 Horizontal Bracket 3D DWG



SKP

EX26 Vertical Bracket SKP

EX26 Vertical Bracket SketchUp



DWG

EX26 Vertical Bracket 3D DWG

EX26 Vertical Bracket 3D DWG



SKP

EX26 115V SKP

EX26 115V SketchUp



DWG

EX26 115V 3D DWG

EX26 115V 3D DWG



SKP

EX26 230V SKP

EX26 230V SketchUp



DWG

EX26 230V 3D DWG

EX26 230V 3D DWG



SKP

Top hat adapter for ESD10, ESD12, ESD36, ESD6, EX10, EX12, EX26 SKP

Top hat adapter for ESD10, ESD12, ESD36, ESD6, EX10, EX12, EX26 SketchUp



SKP

EX26 Vertical Bracket SKP

EX26 Vertical Bracket SketchUp



DWG

EX26 Horizontal Bracket 3D DWG

EX26 Horizontal Bracket 3D DWG



SKP

EX26 Horizontal Bracket SKP

EX26 Horizontal Bracket SketchUp



PDF

EX26 - 230V - 2D

EX26 - 230V 2D Drawing



PDF

EX26 - 115V - 2D

EX26 - 115V 2D Drawing



DWG

EX26 2D DWG

EX26 2D DWG



DWG

EX26 Horizontal Bracket 2D DWG

EX26 Horizontal Bracket 2D DWG



DWG

EX26 Vertical Bracket 2D DWG

EX26 Vertical Bracket 2D DWG



SKP

EX Series SketchUp

EX Series SketchUp



DWG

Top hat adapter for ESD10, ESD12, ESD36, ESD6, EX10, EX12, EX26 3D DWG

Top hat adapter for ESD10, ESD12, ESD36, ESD6, EX10, EX12, EX26 3D DWG



GLL

EX26 - EASE data

EASE data - .GLL - description



GLL

EX26 EASE Focus

EX26 EASE Focus





EX26 Cover

Gallery

Product code

KVV 987 209



Description

- heavy duty - padded



EX26 Grill Fine

Product code

KVV 987 351


Description

Grill fine option for EX26


EX26 Horizontal bracket

Gallery

Product code

KVV 987 493



Description

- for EX26 - including two connection bolts and holder



Downloads

DWG

EX26 Horizontal Bracket 3D DWG

EX26 Horizontal Bracket 3D DWG

SKP

EX26 Horizontal Bracket SKP

EX26 Horizontal Bracket SketchUp

DWG

EX26 Horizontal Bracket 2D DWG

EX26 Horizontal Bracket 2D DWG

EX26 Vertical bracket

Gallery

Product code

KVV 987 492



Description

- for EX26 - including two connection bolts



Downloads

DWG

EX26 Vertical Bracket 3D DWG

EX26 Vertical Bracket 3D DWG

SKP

EX26 Vertical Bracket SKP

EX26 Vertical Bracket SketchUp

DWG

EX26 Vertical Bracket 2D DWG

EX26 Vertical Bracket 2D DWG

Speaker pole - universal

Gallery

Product code

KVV 987 130



Description

Heavy duty telescopic speakerpole
- 0,735 to 1,23 m - diameter 35 mm
- weight 2,2 kg - max. load 50 kg
- bottom terminal M20
- matte black



Downloads

SKP

Speaker pole - universal SKP

Speaker pole - universal SketchUp

Top hat adapter for ESD10, ESD12, ESD36, ESD6, EX10, EX12, EX26

Gallery

Product code

KVV 987 090



Description

- including bolts - black



Downloads

DWG

Top hat adapter for ESD10, ESD12, ESD36, ESD6, EX10, EX12, EX26 3D DWG

Top hat adapter for ESD10, ESD12, ESD36, ESD6, EX10, EX12, EX26 3D DWG

SKP

Top hat adapter for ESD10, ESD12, ESD36, ESD6, EX10, EX12, EX26 SKP
